Biological Septic Tank

ECODEPUR® BIOFIX > 50 HE

The ecological solution for wastewater treatment

More than 50 equivalent inhabitants

The Biological Septic Tank, ECODEPUR® BIOFIX is a compact wastewater treatment system that combines primary settling, sludge anaerobic digestion and aerobic biological filtration, for the reception and advanced treatment of domestic wastewater or wastewater of similar characteristics.

Particularly suitable for single-family homes, the Biological Septic Tank, ECODEPUR® BIOFIX delivers excellent treatment performance, achieving high removal efficiencies for BOD₅ (Biochemical Oxygen Demand) and Total Suspended Solids (TSS).

  • High performance biological filter;
  • Light and easy to install and maintain;
  • Easy to install and maintain;
  • Total watertightness (due to the material in which they are built, there are no leaks through the constituent walls, unlike traditional concrete systems);
  • No unpleasant odours, with adequate ventilation;
  • No power consumption.
biofix-1.2
ModelHAB (hab/eq)Volume (m3)Flow (l/s)Length (mm)Diameter (mm)Width (mm)Height (mm)He (mm)Hs (mm)C (mm)Pipe Diameter (mm)Documents
BIOFIX VT20--6.5202.190-2.2651.800150790200
BIOFIX VT25--8.0602.190-2.2651.800150790200
BIOFIX VT30--9.6002.190-2.2651.800150790200
BIOFIX VT35--11.1402.190-2.2651.800150790200
BIOFIX VT40--12.6802.190-2.2651.800150790200
BIOFIX VT45--14.2202.190-2.2651.800150790200
BIOFIX MR VT50--8.5202.980-3.0502.600112790200
BIOFIX MR VT60--10.0602.980-3.0502.600112790200
BIOFIX MR VT70--11.6002.980-3.0502.600112790200
BIOFIX MR VT80--13.1402.980-3.0502.600112790200
BIOFIX MR VT90--14.6802.980-3.0502.600112790200
BIOFIX MR VT100--16.2202.980-3.0502.600112790200
BIOFIX MR VT110--17.7602.980-3.0502.600112790200
BIOFIX MR VT120--19.3002.980-3.0502.600112790200
  • Caption: C - Cover | He - Inlet pipe level | Hs - Outlet pipe level
  • All measurements are given in millimetres, with a tolerance of ±2%, and may be changed without prior notice.

How the ECODEPUR biological cesspit works® BIOFIX is based on three different processes:

  • Settling: the sludge settles, separating the solid phase from the liquid phase;
  • Anaerobic digestion: the sludge undergoes anaerobic digestion and the organic matter is mineralised;
  • Aerobic biological filtration: biological removal of soluble organic matter through the biomass developed in the filling medium.
Sports complexes
Micro-agglomerations of up to 25 inhabitants
Camping sites
Condominiums
Allotments
Villas

ECODEPUR® AIR FILTER

Cast iron lid

Technical documentation

Equipment Catalogue
Autocad
BIM
Text Prescription
