ECODEPUR® GORFEC starch separators

High capacity for separating and storing fats and starches

The ECODEPUR® GORFEC Fat and Starch Separators are equipment designed to receive and process
waste water contaminated with fats and starches from domestic or industrial use, originating from the
food handling.

They are made of polyethylene, a material with high mechanical resistance and insensitivity to corrosion that has been duly tested.
by an independent organisation (Laboratório Nacional de Engenharia Civil - LNEC), in accordance with the requirements of the EN Standard
1825-1.

CE marking EN1825-1;
Sludge trap incorporated;
Cover to protect internal components;
Possibility of incorporating a by-pass and an acoustic and luminous alarm probe directly into the structure of the equipment;
High storage capacity for separated products;
Easy to install and maintain;
Light and easy to install and maintain;
Totally watertight (due to the construction materials, there are no leaks in the walls, in contrast with the traditional concrete systems);
No unpleasant odours with adequate ventilation;
No power consumption.

Model	HAB (hab/eq)	Volume (m3)	Flow (l/s)	Length (mm)	Diameter (mm)	Width (mm)	Height (mm)	He (mm)	Hs (mm)	C (mm)	Pipe Diameter (mm)
GORFEC NS 1,5	-	1.360	-	1.560	-	960	1.230	930	820	750 x 750	110
GORFEC NS 3	-	2.410	-	2.580	-	960	1.230	930	820	750 x 1415	110
GORFEC NS 6	-	3.770	-	4.060	-	960	1.230	915	805	(750x750) + (750x1.415)	125
GORFEC NS 8	-	4.820	-	5.080	-	960	1.230	880	770	2 x (750x1.415)	160

The operation of grease separators requires no energy consumption and is based on the gravitational separation of materials with a different density to water. The heavier materials (sludge, sand, etc.) settle in the pre-decantation compartment.
being held there.

This compartment also retains fats that are in easily flotable forms. Only water and substances lighter than water, namely the fats to be separated, pass into the separation zone.

The grease accumulates on the surface, while the clean water comes out at a level that doesn't allow the phases to mix.
