Oil Water Separator

ECODEPUR® OILTECH

Solução para a prevenção da contaminação por hidrocarbonetos

The ECODEPUR® OILTECH is a system designed to separate and retain hydrocarbons present in wastewater from car parks, garages, petrol stations, industrial estates and other areas prone to contamination by oils and fuels.

Fabricado com materiais de elevada resistência e durabilidade, o sistema garante um tratamento eficiente, assegurando que a descarga de águas contaminadas cumpra os limites legais de poluição. A sua tecnologia de separação por gravidade, associada a um filtro coalescente de alto desempenho, permite remover eficazmente partículas oleosas e suspensas do efluente.

The OILTECH model can be equipped with an Automatic closure device, which prevents the release of hydrocarbons in the event of separator saturation, thereby enhancing operational safety. Its modular design facilitates installation, inspection, and maintenance, making it an ideal solution for companies seeking efficiency, reliability, and full environmental compliance.

In line with our commitment to providing credible and verifiable environmental information, ECODEPUR now provides the EPD (Environmental Product Declaration), for hydrocarbon separators ECODEPUR^® OILTECH, developed in accordance with ISO 14025:2006 and EN 15804:2012+A2:2019/AC:2021 and verified by a third party. We believe that sustainability is built on facts, rigour and transparency.

^{EPD-IES-0031225:002}

CE Marking according EN 858-1;
High treatment levels (double filtration system);
Automatic closure device (massive anti-miscalibration system);
Built-in sample collection device;
Protective cover for internal components in PE;
Possibility of incorporating a by-pass and an acoustic and luminous alarm probe directly into the structure of the equipment;
High mechanical resistance and corrosion protection;
Light and easy to install and maintain;
Easy to install and maintain;
Totally watertight;
Without power consumption;
Low cost.

Model	Volume (m3)	Flow (l/s)	Length (mm)	Diameter (mm)	Width (mm)	Height (mm)	He (mm)	Hs (mm)	C (mm)	Pipe Diameter (mm)
OILTECH NS3	-	-	-	1.210	-	1.380	1.080	1.030	740	110
OILTECH NS6	-	-	1.560	-	960	1.230	915	805	750 x 750	125
OILTECH NS10	-	-	2.580	-	960	1.230	880	770	750 x 1415	160
OILTECH NS15	-	-	4.060	-	960	1.230	840	730	750 x 750 - 750 x 1415	200
OILTECH NS20	-	-	5.080	-	960	1.230	840	730	2 x (750 x 1415)	200
OILTECH NS30	-	-	6.560	-	960	1.230	790	640	2 x (750 x 1415) \| 750 x 750	250

Oil Water Separator admits non-chemically emulsified oily water containing hydrocarbons with densities between 0.85 and 0.95. The heavier materials (sludge, sand, etc.) sediment in the pre-sludge trap zone and are retained there. This compartment also retains hydrocarbons that are in easily floatable forms. Only water and substances lighter than water, namely the hydrocarbons to be separated, pass into the separation zone. The separators are equipped with a coalescing filter, which allows the smaller oil particles to aggregate into larger particles. Aggregation of the particles increases the upward force sufficient to release them from the main flow lines towards the surface. In this chamber, the hydrocarbons accumulate on the surface, while the treated water exits through the bottom of the equipment.

The Oil Water Separator is equipped with an automatic closure device (massive anti-miscalibration system), which prevents hydrocarbons from escaping once the equipment's maximum holding capacity has been reached, thus preventing contamination of the receiving environment. The operation of the Oil Water Separator does not require energy consumption and is based on the gravitational separation of materials with a different density to water, assisted by the presence of an oleophilic coalescing cell.
